POWERPLUS range of forklifts

With competitive running costs, powerful engine with environmental protection, our forklifts are designed for ultimate maneuverability and lifting capacity that could effortlessly perform the job with ease. Ergonomically cabin design and safety features enable driver to operator this mighty vehicle with precise control and seamlessly glide through every tight corners with maximum efficiency.

Featuring Japanese Isuzu, Mitsubishi, Yanmar and Deutz engines

  • Wide foot room & suspension foot brake
  • Dual suspension system
  • Reinforced mast design







Epitomize the highest levels of performance and productivity.



PFD180S-VI
Diesel Forklift 1.8 Ton

DESIGN

An all new integrated dashboard makes for luxurious comfort for the operator who spends hours behind the wheel. It also allows for an increased 30% storage space resulting in higher productivity. Willi the Improved streamline design from Its predecessor, the ergonomically designed V-Serles of Forklifts is in a class of Its own.

COMFORT

A larger legroom provides exceptional comfort and a small steering wheel makes it easier for the operator to engage tight corners. This new and improved model also boasts of a dual suspension system which significantly reduces noise and vibrations from the engine and transmission. Enhancements like the newly­ designed handbrake and suspension foot brake is incorporated Into this exclusive range.

SAFETY

Safety In the workplace is of utmost importance to POWERPLUS. The wide view mast which Improves visibility from 680mm to 750mm ensures safety for both the operator and the people working around the forklift. Both the canopy and cabin configurations are reinforced by incorporating profiled steel and acrylic glass on the ceiling with the aim to protect the operator from any falling objects or from rolling over.

STABILITY

In a bid to provide better parts and service support, we have standardized most components across our smaller capacity forklifts. For instance. the cabin can be Installed on the standard canopy configuration without any modifications. Furthermore, most of the operation components such as the engine covet. Instrument panel, safeguard and display, just to name a few are interchangeable across the 1.0 to 4.0 ton range.

Technical Specifications - At a Glance
Model PFD150S-VI PFD180S-V PFD200S-VI PFD250S-VI PFD300S-IV PFD 350S-VI
Load Capacity 1500 kg 1800 kg 2000 kg 2500 kg 3000 kg 3500 kg
Load Center 500 mm 500 mm 500 mm 500 mm 500 mm 500 mm
Engine Model ISUZU C240 ISUZU C240 MITSUBISHI S4S (Made in Japan) / ISUZU C240 MITSUBISHI S4S (Made in Japan) / ISUZU C240 MITSUBISHI S4S (Made in Japan) / ISUZU C240 MITSUBISHI S4S (Made in Japan) / ISUZU C240
Rated Power 32 HP @2500 rpm 32 HP @2500 rpm 51 / 46 HP @ 2300 / 2500 rpm 51 / 46 HP @ 2300 / 2500 rpm 51 / 46 HP @ 2300 / 2500 rpm 51 / 46 HP @ 2300 / 2500 rpm
Lifting Speed (laden) 460 mm/s 460 mm/s 490 mm/s 490 mm/s 470 mm/s 470 mm/s
Travelling Speed (laden) 14.5 km/h 14.5 km/h 19 km/h 19 km/h 20 km/h 20 km/h
Overall Length (Without fork) 2250 mm 2250 mm 2570 mm 2570 mm 2705 mm 2746 mm
Overall Width 1086 mm 1086 mm 1160 mm 1160 mm 1230 mm 1230 mm
Turning Radius 2060 mm 2060 mm 2240 mm 2240 mm 2410 mm 2445 mm
Overall Height (J) 2040 mm 2040 mm 2060 mm 2060 mm 2090 mm 2090 mm





DIMENSION AND RANGES

CAPACITY CHART

More Reasons to Choose WWTEG


One-Stop Service Solution

This one-stop center is achieved through a network of highly certified OEM manufacturers, and effective distribution of spare parts throughout all our vendors globally. Easily determine, locate, order and promptly receive exact parts you require from our POWERPLUS Parts Service Center.


International Warranty

Every POWERPLUS equipment is covered by international warranty, that is recognized by all our authorized agents and distributors. Our construction equipment is covered for 1 year or 2,500 operational hours (whichever comes first), while our range of trucks is covered for 1 year or 100,000 hours (whichever comes first).


Genuine Parts

Every genuine POWERPLUS part is designed and manufactured with quality, durability, and reliability in mind. Considerably minimize equipment downtime, avoid consequential damages, as well as safeguard the validity of warranty claims by using only genuine spare parts.
